| 【Prev Products】 | 【Next Products】 |
 |
|
|
|
| Type | XMTE |
| Power Supply | AC220V |
| Input |
K/ E/ J/ PT100 (0-399℃) |
| Output | RELAY |
| Accuracy of Measurement | ±0.5% |
| Outline Dimension | 48*96mm |
| Install Dimension | 45*92mm |
| Operating temperature | 0-50℃ |
| Compensating error of cold side | ±2℃(the software corrects the data for 0-50℃ fluctuations in temperature ) |
| Control Mode |
Adopt industrial and PID Parameters of Control System,Temperature Control, responsible faster,Start modulation smaller, accuracy higher than troditionalPID |
Send InquiryIf you have any enquiry about quotation or cooperation,please feel free to email us at Cecilia@cnchog.com or use the following enquiry form. Our sales representative will contact you within 24 hours. Thank you for your interest in our products.
