5/16 WRNT-03&WRET-03&WRJT-03

You are here: Home » What We Do

5/16 WRNT-03&WRET-03&WRJT-03

CG 5/16' K J PT100 Type 1m 2m 3m 5m Wire Cable 50mm 100mm 150mm 200mm Probe Thermocouple Temperature Sensor for Temp Controller
E-mail Us  PDF Download
【Prev Products】 【Next Products】

If you want other type probe length or screw, please check our store or connect Customer Service.

PS: The length of thermocouple is probe length + cable length. for example: 1m probe 100mm, 1m=100mm probe+ 900mm cable outside.

Model Number: WRNT-03&WRET-03&WRJT-03
Brand Name: CG
Theory: Temperature Sensor
Usage: Industrial
Accuracy: ±1.5℃
Type: K,E,J
Temperature range: 0-800degree
cable length: 1-5m(customized)
Wire diameter: 0.3,0.45mm
Certificate: ISO9001
Temperature Sensor Furnace
Type Temp Range
Thermocouple B: PtRh30-Pt6 0~1600℃
R: PtRstrong3-Pt 0~1300℃
S: PtRstrong0-Pt 0~1300℃
N: NiCrSi-NiSi 0~1000℃
K: NiCr-NiSi 0~900℃
E: NiCr-CuNi 0~600℃
J: Fe-CuNi 0~500℃
T: Cu-CuNi 0~350℃
Type Temp Range
RTD Sensor PT100 -200~+650℃
PT1000 -200~+650℃
CU50 -200~+650℃

Name Model NO indexing Structure feature

Imitate imports Proble type thermocouple / thermal resistance

WRNT-03 K

fixing thread:

5/16"-22 BSF

Protection tube:

φ5

WRET-03 E
WRJT-03 J
WZPT-03 PT100
WZCT-03 Cu50
